Pelican 1745 Air Long Case, Trekking Green with TSA Locking Latches

Details

Pelican 1745 Air Case

• Interior:44.01″ x 16.77″ x 7.94″
• Weight (Empty): 17.26 lbs
• Series:Air Case
• Case Color: Trekking Green
• Handles & Latches Color: Black
• Latches Type: TSA Locking Push-Button
• Keys: Yes (2)
• Wheels:Yes (2)

• Features

• Dimensions

• Specs

• Accessories

• Drawings

• • Watertight rubber O-ring seal, crush-proof, and dust-proof
  • Automatic pressure equalization/purge valve that balances air pressure inside the case
  • Super-lightweight proprietary HPX Polymer
  • Polyurethane wheels with stainless steel bearings for rolling travel
  • Four easy-to-open push-button latches & 2 TSA approved locking latches
  • Ergonomic comfort grip rubber over-molded handles
  • Card holder that can be placed on the front or side of the case
  • Stainless steel hinge pins and reinforced padlock protectors
  • IP67 & MIL-SPEC certified
  • Genuine Pelican product with lifetimewarranty
• • Lid Depth: 2.00″ (5.1 cm)
  • Bottom Depth: 5.94″ (15.1 cm)
  • Total Depth: 7.94″ (20.2 cm)
  • Interior (L X W X D): 44.01″ x 16.77″ x 7.94″ (111.8 x 42.6 x 20.2 cm)
  • Exterior (L X W X D): 46.69″ x 19.36″ x 8.73″ (118.6 x 49.2 x 22.2 cm)
  • Weight (Empty): 17.26 lbs (7.8 kg)
  • Weight (With Foam): 20.06 lbs (9.6 kg)
• • Internal Volume: 3.39 ft (0.096 m)
  • Case Material: Polypropylene
  • Latch Material: ABS
  • Pins Material: Stainless Steel
  • Purge Body Material: ABS
  • Purge Vent Material: 3 Micron Hydrophobic Non-Woven
  • Wheels Material: Polyurethane, Stainless Steel

• Pick & Pluck Foam

  • Pelican Pick & Pluck foam is a 1.3 lb polyurethane foam with a perforated 1/2″ x 1/2″ grid of removable foam squares. Remove only what you need for a customized fit.

• Download CAD Drawings*

  • Pelican 1745 Air Case Dimensional Drawing
